Zephyr Modena Island Guide D'utilisation, D'entretien Et D'installation page 15

Installation Instructions
ZEPHYRONLINE.COM
13-11/16"
14-3/16"
8-1/4"
STANDARD
min. ducted - 28"
min. recirc. - 32"
max. - 50"
Z1C-00MD
min. ducted - 43"
min. recirc. - 46"
max. - 80"
35-7/16", 41-15/16"
27-1/2"
Front
Side
11-5/8"
5-7/8"
C/L
11-3/8"
C/L
C/L
AC In
2-3/8"
5-1/4"
Top Support Frame
Top of Hood
(top view)
15
Modena Island Use, Care, and Installation Guide
