E N G L I S H
Also refer to the table below.
2
Conductor size (mm
)
Cable rating (Amperes)
0.75
6
1.00
10
1.50
15
2.50
20
4.00
25
Cable length (m)
7.5
Voltage
Amperes
Cable rating (Amperes)
115
0 - 2.0
6
2.1 - 3.4
6
3.5 - 5.0
6
5.1 - 7.0
10
7.1 - 12.0
15
12.1 - 20.0
20
230
0 - 2.0
6
2.1 - 3.4
6
3.5 - 5.0
6
5.1 - 7.0
10
7.1 - 12.0
15
12.1 - 20.0
20
Voltage drops
Inrush currents cause short-time voltage drops.
Under unfavourable power supply conditions,
other equipment may be affected.
If the system impedance of the power supply is
lower than 0.25 ø, disturbances are unlikely to occur.
Assembly and adjustment
Prior to assembly and adjustment always
unplug the tool.
Depth of cut adjustment (fig. A)
• Loosen the adjustment system by lifting the lever (3).
• Raise or lower the front handle (5) to set the
correct depth of cut.
• Expose the blade to check the depth of cut.
• Lock the adjustment system by pushing the lever
(3) down.
For optimal results, allow the saw blade
to protrude from the workpiece by about
5 - 8 mm.
en - 5
DW383.PM65
15
25
30
45
60
6
6
6
6
10
6
6
6
15
15
6
10
15
20
20
10
15
20
20
25
15
20
25
25
-
20
25
-
-
-
6
6
6
6
6
6
6
6
6
6
6
6
6
10
15
10
10
10
15
15
15
15
15
20
20
20
20
20
25
-
18
Mounting and adjusting the parallel fence
(fig. A & E)
The parallel fence (6) is used for cutting parallel to
the edge of the workpiece.
Mounting
• Insert the parallel fence (6) in the saw shoe (10)
as shown.
• Insert the bolt (18) into the hole (19).
• Place the clamping bracket (20) over the bolt and
tighten the locking screw (14).
Adjusting
• Slacken the locking screw (14) and set the
parallel fence (6) to the desired width. The
adjustment can be read on the scale (17).
• Tighten the locking screw (14).
The marks (21) and (22) can be used as a guide:
mark (21): for standard steel blades
mark (22): for TCT blades
Bevel adjustment (fig. A & B)
The bevel angle can be adjusted between 0° and 45°.
• Slacken the locking screw (13).
• Set the bevel angle by tilting the saw shoe (10).
The angle can be read on the bevel scale (12).
• Tighten the locking screw (13).
Removing and installing the saw blade (fig. C)
• Open the blade guard (7).
• Rotate the saw blade until a screwdriver can be
inserted into the hole in the blade. This will prevent
the blade from rotating while being loosened.
• If no screwdriver is available, or if the saw blade
used does not have a hole, lock the blade by
pressing the teeth into a piece of wood.
• Loosen and remove the blade bolt (8) and the
outer arbour collar (23) using the wrench
supplied.
• Replace the saw blade. The teeth must point in
the direction of rotation, which is shown by the
arrow on the upper guard housing.
• Reinstall the outer arbour collar and tighten the
blade bolt (8).
