5.2

Cold silanization in the sandblasting unit

The Basic series of Renfert sandblasting units is exclusively recommended by
3M ESPE for use with ROCATEC™. This bonding system is ideal if an adhesive bond is required between a composi-
te and a dental material (metal, acrylic, porcelain, zirconia porcelain).
Advantage: The surface film is applied cold, preventing thermal loading of metal frameworks and consequently the
risk of distortion. All units in the Basic series can be used for ROCATEC™ due to their regular, homogeneous jet flow.
6.

Cleaning / Maintenance

Before cleaning or servicing:
► Switch off and unplug the device!
► Disconnect the appliance from the compressed air supply!
6.1

Cleaning the Interior

EN
• DO NOT use solvent-containing cleaning agents or disinfectants. (use e.g., soapy water)
• Remove the grate and vacuum the blasting chamber.
• Wipe out the tanks and lids only with a dry cloth!
6.2

Condensation

• Inspect the water separator (21).
• Drain any water off through the valve (21a).
6.3

Blasting Nozzle Replacement

• For installation see accessory supplement.
6.4

Cleaning the dosing nozzle

The dosing nozzle from the mixing chamber can become blocked due to contamination
and moist blasting sand.
For cleaning, the dosing nozzle is removed using the supplied tool and replaced after
cleaning.
• Vacuum clean the blasting tank completely.
• Hold the dosing nozzle with the tool and pull upwards (fig. 11).
• Clean the dosing nozzle (e.g. blow with compressed air).
• Replace dosing nozzle.
Before remounting, the dosing nozzle should be completely dry!
• The dosing nozzle must be adjusted with blasting tanks of 25 - 70 µm (fig. 12)!
see also supplement „Cleaning the dosing nozzle"
6.5

Lamp cover

In the course of time, the lamp cover can become matt. This cover can be ordered as a spare part.
6.6

Spare Parts

You can find components subject to wear and the spare parts on the spare part list in the internet at
www.renfert.com/p918.
The components excluded from the warranty (such as consumables or parts subject to wear and tear) are marked on
the spare part list.
Serial number and date of manufacturing are shown on the type plate of the unit.
6.7

Shipping Notes

• Empty all blasting tanks.
• Order Renfert transport packaging (Tel. +49 7731 8208-383)
The return form can be downloaded from the „Advice" section on the Renfert website at www.renfert.com.
EN
- 6 -
fig. 9
21
21a
fig. 10
fig. 11
fig. 12
