6. Description of the Operating Elements of the Sharpener
The figure can be found on a folding out page at the beginning of the operating instructions.
1 Hand lever for movements of the grinding carriage
2 On/off switch („I" = on, „O" = off)
3 Fastening nut for inclination position
4 Degree indication for inclination setting
5 Bottom plate
6 Holder for grinding carriage
7 Attachment screw for grinding carriage (total of 4 screws, one per corner)
8 Attachment screw for grinding carriage (total of 4 screws, one per corner)
9 Attachment screw for the holding arm of the counterpressure spring
10 Holding arm for the counterpressure spring
11 Attachment screw for the holding rod of the counterpressure spring
12 Holding rod for the counterpressure spring
13 Counter-nut for the saw blade support
14 Saw blade support
15 Counterpressure spring
16 Fastening screw for the saw blade
17 Transparent protective cover
18 Fastening wheel for the saw blade arm
19 Cover for the grinding disc
20 Depth stop for the grinding carriage, with fastening screw
21 Holding rod for the saw blade arm
22 Saw blade arm
The displayed saw blade only serves illustration purposes. It is not enclosed in the delivery.
