Installation instructions, only for experts

4. Installation and connection

Take the following points into account when positioning and connecting the
sauna heater:
WARNING!
Danger of electric shock
● The sauna heater may only be installed and connected when the
power supply is disconnected.
● The electrical connection may only be performed by a qualified electrician or
similarly qualified person.
● A fully disconnecting all-pole isolating device compliant with overvoltage
category III must be fitted on site.
● The Concept R mini sauna heater is a wall-mounted heater. Before starting
the heater, check that the heater has been firmly installed on the mounting rail.

4.1. Installation location and sensor position

Position the heater centrally in front of the air intake opening on the cabin wall.
Observe the safety distances to the cabin wall specified in Fig. 1.
Install the temperature sensor with excess temperature cut-out to the cabin wall
above the centre of the sauna heater. Maintain a distance of 15 cm to the sauna
cabin roof.
p. 10/28
