Safety instructions
The CT-ASA is intended for securing on
the dust extractors of the CT 22/33/44/55
and CT 26/36/48 series.
Apart from the suction hose and the
power cable, no objects (e.g. electric
power tools) must be secured to or hung
on the CT-ASA.
There must be no lateral forces acting
on the CT-ASA. The tensile force on the
suction hose must not exceed 50 N.
Fit the handle (CT-SB) before attaching the
CT-ASA to your mobile dust extractor.
CT 26/36/48 only: attach the accompanying
support (CT 26/36-ASA/SB).
Assembly
The specifi ed illustrations can be found at the
beginning of the assembly instructions (Fig. =
Figure).
The CT-ASA can be secured in two positions:
pointing away from the dust extractor or pointing
at the dust extractor (see title illustrations).
Fig. 1: Secure the two cross members (1.1) to
the two support tubes (1.2).
Fig. 2: Secure the two support tubes with the
brackets (2.2) to the handle (2.1). Align
the height of the support tubes such
that they are lying on the floor and
tighten the four screws (2.3).
The support tubes must point in the
same direction as the subsequently
mounted upper tubes of the CT-ASA.
The CT-ASA must only be operated with
properly mounted support tubes.
Fig. 3: Secure the tube clamp (3.1) to the hand
grip of the handle, but do not tighten the
screws yet.
Fig. 4: - Only CT 22/33/44/55: Push the tube clip
(4.2) approx. 50 mm onto the lower tube
(4.3).
- Engage the lower tube into the pipe
clamp (4.4) and into the bracket (4.5),
and push it vertically downwards onto
the support (4.1).
Fig. 5: - Secure the spring (5.1) to the tube clamp.
Tighten the tube clamp screws.
- Only CT 22/33/44/55: Push the tube clip
(5.3) upwards as far as the bracket (5.2)
and tighten the tube clip screw.
The lower tube must now sit fi rmly and
you must not be able to move it any
more.
Fig. 6: - Attach the movable tube (6.1) onto the
lower tube (6.3) and screw it in tight (the
screw must go through the boreholes
(6.2) of both tubes).
The movable tube can be swivelled in a
range of 90°.
- Insert the extension tube (6.5) into the
movable tube (6.1) until it engages with
the ball (6.4) there.
Fig. 7: - Insert the suction hose (7.3) supplied
with the CT-ASA into the vacuum
cleaner. Secure the suction hose (7.1)
leading to the electric power tool in the
brackets (7.4) and join the two suction
hoses together with the joining sleeve
(7.2).
- Insert the power cable (7.7) supplied
with the CT-ASA into the appliance
socket of the vacuum cleaner and
secure the end of the coupling in the
bracket (7.6). Secure the power cable
(7.5) leading to the electric power tool
in the brackets (7.4) and join both power
cables together.
The CT-ASA is now ready for opera-
tion.
Fig. 8: For transport, you can remove the two
cross members (8.1) of the support
tubes (8.2) and swivel the support tubes
towards the dust extractor. You can lay
down the cross members in the support
tubes.
