Intended use

/// Use
• The magnetic stirrer is suitable for mixing and / or heating subs-
tances.
/// Area of use
• Indoor environments similar to that a laboratory of research,
teaching, trade or industry area.
• The safety of the user cannot be guaranteed:
- if the device is operated with accessories that are not supplied
or recommended by the manufacturer,
- if the device is operated improperly or contrary to the
manufacture's specifications,
- if the device or the printed circuit board are modified by third
parties.

Unpacking

/// Unpacking
• Please unpack the device carefully
• In the case of any damage a detailed report must be sent
immediately (post, rail or forwarder)
/// Scope of delivery
• Heating magnetic stirrer
• Mains cable
• Operating instructions
• Screwdriver
• Protective cover
• Temperature sensor PT 1000

Assembling the stand

• Remove screw plugs (M).
• Remove the protective cap from the support rod.
• Put the washer between housing and nut.
• Screw the support rod onto the device
by hand until the end stop is reached.
• Use an A/f 17 spanner to tighten the
M10 nut.
• Accessories should be attached using
cross sleeves.
Note: When using bath attachments
with a diameter over 180 mm, please
use support rod in conjunction with an
extension. (See "Accessories")
Risk of tipping!
Make sure that the center of mass of the
attached device does not protrude over
the safe area indicated with a dashed
rectangle.
safe area
