Faiveley 12 - entrematic PSL Retrofit Kit Manuel D'installation

Faiveley 12

DIN 6921 (M6SF)
32
M6x12 FZB 8.8 (6x)
25
4
ISO 14583 (MRT-TT)
M6x10 FZB 8.8 (4x)
1018482-EMfr-FR-3.0
Square nut M6 (6x)
29
27
4
ISO 14583 (MRT-TT)
M6x10 FZB 8.8 (6x)
Square nut M6 (4x)
29
24
24 Support de connexion
25 Support 1
27 Plaque de montage
28 Support de montage
Edition 2020-03-12
ISO 7089 (BRB)
14
6.4x12x1.5 FZB (6x)
27
11
DIN 6921 (M6SF)
M6x8 FZB 8.8 (6x)
28
27
DIN 6921 (M6SF)
32
M6x12 FZB 8.8 (4x)
4 Installation mécanique
45
