Necessary combustion-improving parts to be used with steel boilers
with large combustion chambers, cast-iron boilers and heaters as accessory
For burner types: KG/UB20-P / KG/UB20 / KG/UB55 when burning Vegetable oil
Pos. Reference
a) 038673
b) 038766
For burner types: KG/UB70 / KG/UB100 / KG/UB150 / KG/UB200
Series 04
Reference
039360
039361
039362
Ceramic fibre board – necessary for all burners when used with steel boilers with
large combustion chamber or cast-iron boilers with a vertical rear panel in the
combustion chamber.
36
ZVP-tube to lower the flue gas temperature, to raise the CO
values and to lower the soot created.
Kit consists of:
a) to be used in boilers:
ZVP-tube with Ø 142 mm and fibre mat
b) to be used for heaters 25S and 40S:
ZVP-tube with Ø 125 mm
Face-to-
face
length
[mm]
ZVP 140 220
ZVP 125 220
Ceramic tube to lower the flue gas temperature, to raise the CO
values and to lower the soot created.
Kit consists of ceramic tube and base.
Face-to-
face length
[mm]
410
490
530
Outer Ø
Inner Ø [mm]
[mm]
140
142
125 127
Outer Ø
Inner Ø
[mm]
[mm]
200
250 300
250 300
Material : Ceraboard 115
Can be used up to a maximum temperature of
1.400 °C
Reference
039395 500 x 500
To be used for
KG/UB20P, 20, 55 – for boiler
KG/UB20P - heater 25S
KG/UB20 - heater 40S
To be used for
boilers
KG/UB70
KG/UB100
KG/UB150, 200
Length X
Thickness
Width
[mm]
[mm]
25
2
2
