EN
ENGLISH
Type approval:
Rated voltage
Operating voltage
Total current
consumption
Interference
15
suppression class
Power
consumption
Dome
Operating position Upright
Protective rating
Temperature range minus 40 ºC to plus 60 ºC
Inverse polarity
protection
Housing
Interference
suppression class 4
Technical Data
Format: ECE R65 TA1 (E1) 004154
ECE R65 TB1 (E1) 004155
ECE R65 TR1 (E1) 004255
SAE W3-2
C-Tick E1511-0734
12 V / 24 V
9-32 V
12 V: approx. 0.9 A
24 V: approx. 0.4 A
CISPR25,
Suppression level 4
12 V: approx. 10 W
24 V: approx. 10 W
PC
IP5KX, IPX4K, IPX9K
yes
EPDM
ECE R10 057696
APPROVAL
Hella rotating beacons ROTA LED Art. No. 012 878-XXX
- Flashing, have been offi cially type-tested within the
scope of ECE-R65. They need to be mounted at the
highest point of the vehicle and when the vehicle is
loaded during operation they must be vertical to the
road surface. All rotating beacons are RFI suppressed
and comply with UNECE R10 Rev05 Part 2. They are
EC-approved according to Directive 72/245 EEC in version
2006/28 EC.
ELECTRICAL CONNECTION
(fuse-protected positive line) Use a cable cross-section
2
of at least 1.5 mm
, 10 A slow-blow fuse.
+
+
–
red
+
30
–
31
blue
yellow
–
