FILLING INFORMATION
4. Your humidifier is equipped with one water bottle.
When both the water bottle and reservoir have
emptied, the humidifier fan will automatically
shut off, but will start again automatically when
the water bottle and reservoir are refilled.
5. When the bottle is being filled for the first time and
the wick is still dry, it will take approximately 20
minutes to drain the bottle into the reservoir. After
the bottle has emptied, it should be refilled again to
obtain maximum running time.
6. When refilling the bottle and the wick is still wet, it
will take approximately 12 minutes to refill the re-
servoir. At this time, you should refill the bottle for
maximum running time.
CASTERS
7. Turn the emptied cabinet upside down. Insert each
caster stem into the four caster holes on each
corner of the humidifier bottom. The casters should
fit snugly and be inserted until the stem shoulder
reaches the cabinet surface. Do not force.
8. Turn the cabinet right side up.
EVAPORATIVE WICK
9. When placing the wick back into the humidifier, the
rod and float assembly must also be reattached. In
sert the top of the float rod through the hole on the
extended wick retainer (attached to the top of the
wick frame). (A). Holding the float in place, lower the
wick and float assembly together into the cabinet.
The wick has a mounting rib on the top edge which
hooks over a rib at the inside back of the cabinet.
NOTE: The float rod retainer must be extended prior
to inserting the float rod. The white float must be
positioned into the pocket in the bottom of the cabi-
net. (B).
B - 3
A
B
B
AIR CLEANING FILTER (OPTIONAL)
10. The AirCare filter has four tangs that engage into
four keyhole slots that mount the AirCare filter
onto the outside of the back of the cabinet. (C).
Operating manual – Humidifier B 200
