Led Indicator - RADSON H&C module 24V Guide Utilisateur

3.
Possible combinations (7, 11, 13 zones)
MASTER 6 ZONES
MASTER 6 ZONES
MASTER 6 ZONES
4.

LED indicator

LED 1: Green
Orange
Red Blinking
LED 2: Blue
Blue Blinking
LED 3: Red
LED 4 to 6:
+
H&C MODULE
+
SLAVE 4 ZONES
+
SLAVE 6 ZONES
=> System in standby
=> Pump indicator (minimum
one demand from a zone)
=> Sensor Error
=> Cooling Mode indication
=> Humidity drier is activated
=> Heating Mode indication
=> Not used
5
+ H&C MODULE
+ H&C MODULE
