Technical Characteristics; Function And Description - RADSON H&C module 24V Guide Utilisateur

1.

Technical characteristics

Operating temperature
Protection
Power supply
Output :
Heat
Cool
Humidity drier
2.

Function and description

- The Heat & Cool module 24V combined with the UFH digital main zone
programmer is an adjunction module which works with a UFH MASTER 24V.
- This module permits to control and connect all heat & Cool equipments of your
house. (Heat Pump or Separate systems with Boiler and Water Chillers...)
- This module is also equipped with1 special supplementary zone to connect the
UFH main zone programmer.
- Available for 3 types of heating and cooling installations:
Installation1: Separate systems or slave heat pump
Installation2: Reversible Heat pump (manual or automatic)
Installation3: Reversible Heat pump (without Heat&Cool information and control)
0°C - 50°C
Class I - IP20
Done by the UFH Master 24VAC
Carreful:
Before plugging replace the existing fuse on the
UFH Master by the new supplied fuse.
5x20 3,15AT
Relay 0,5 A 24V (L, N)
Relay 0,5 A 24V (L, N)
Relay 0,5 A 24V (L, N)
4
