Specifications
Inputs:
Line:
Front Mic:
Mic 1/Mic 2:
Outputs:
Line:
Headphone:
Distortion:
Signal-to-Noise Ratio (vs. maximum output):
Line:
Front Mic:
Mic 1/Mic 2:
Phono:
Frequency response:
Line:
Mic:
Phono:
Equalization Boost/Cut Amount (Front Mic / Zone A / Zone B):
Bass:
Middle:
Treble:
Power consumption:
10.2 watts typical
12.8 watts with full output
Dimensions/Weight:
19" (W) x 1.75" (H) x 7.87" (D) / 5 lbs
480mm (W) x 44mm (H) x 200mm (D) / 2.2 kgs
6-Channel Stereo Analog Line Mixer with Two Independent Zone Outputs
10K input impedance
140mV rms sensitivity (for 1V output)
10K input impedance unbalanced
1.5mV rms sensitivity (for 1V output)
60mV rms max input
10K input impedance
2.5mV rms sensitivity (for 1V output)
80mV rms max input
9V rms max
0.5 watt into 47 ohms
less than 0.01%
better than 92dB
better than 90dB
better than 80dB
better than 80dB
20Hz - 22KHz +/-0.5dB
20Hz - 18KHz +/-0.5dB
+/-1dB except for controlled attenuation of
-3dB @ 20Hz to reduce rumble and feedback
+/-13dB
+/-14dB
+/-12dB
