• The brake pedal is NOT fully depressed (parking brake
OFF).
Test 2 — Engine SHOULD crank and start if
• The PTO switch is OFF, AND
• The Brake pedal is fully depressed (parking brake ON).
Test 3 — Engine should SHUT OFF if
• The operator rises off the seat with the PTO engaged.
• The operator rises off the seat with the brake pedal NOT
fully depressed (parking brake OFF).
Test 4 — Mower Blade Stopping Time Check
• The mower blades and mower drive belt should come to
a complete stop within five seconds after the PTO switch
is turned OFF.
• If the drive belt does not stop within five seconds, see an
authorized dealer.
Test 5 — Reverse Mowing Option (RMO) Check
• The engine should shut off if reverse travel is attempted
if the PTO has been switched ON and the RMO has not
been activated.
• The RMO light should come on when the RMO has been
activated.
DANGER
Mowing in reverse can be hazardous to bystanders. Tragic
accidents can occur if the operator is not alert to the
presence of children. Never activate the Reverse Mowing
Option (RMO) if children are present. Children are often
attracted to the machine and the mowing activity.

Electronic Dash Panel

Display Total Hours, Trip Hours, and Clock
Note: When you start the unit, the Total Hours show on the
maintenance display. The total hours will set to 0 after 999.9.
1. Push MODE for less than 1 second to show the Trip
Hours.
2. Push RESET for more than 3 seconds to set the Trip
Hours to 0.
3. Push MODE for less than 1 second to show the Clock.
See Set the Clock section.
10
4. Push MODE for less than 1 second to show the Total
Hours.
Set the Clock
1. Push MODE for more than 3 seconds. The hours will
flash on the display.
2. Push RESET to adjust the hours.
3. Push MODE for less than 1 second to save the setting.
The minutes will flash on the display.
4. Push RESET to adjust the minutes.
5. Push MODE for less than 1 second to save the setting.
Maintenance Display
OIL CHANGE - This message shows after 50 hours of
operation. After you change the oil and filter, push MODE two
times to show OIL HRS. Then, push and hold MODE for 3
seconds to set the timer to zero and clear the display.
AIR FILTER CHECK - This message shows after 25 hours of
operation. After you clean or change the air filter, push MODE
three times to show AIR FILTER HRS. Then, push and hold
MODE for 3 seconds to set the timer to zero and clear the
display.
CHANGE BLADES - This message shows after 100 hours
of operation. After you change the blade, hold the RESET
button for more than 3 seconds to set the timer to zero and
clear the display.
LOW BATTERY - This message shows when a battery
voltage problem occurs. The display will automatically clear
after the battery has been serviced.
Note: When the LOW BATTERY message shows on the
display, it has priority over all other messages. Service
the battery first, and then, check for other maintenance
messages.

Engine

Check and Add Engine Oil
®
Use Briggs & Stratton Warranty Certified oils for best
performance. Other high-quality detergent oils are acceptable
if classified for service SF, SG, SH, SJ or higher. Do not use
special additives.
Outdoor temperatures determine the proper oil viscosity for
the engine. Use the chart to select the best viscosity for the
outdoor temperature range expected.
