RODEC
TABLE OF CONTENTS
- Specifications
- Safety instructions
- Installation of the mixing panel
- Frontpanel, switches and control
- Connections
- Operating instructions
- Subsonic filter
- Pictures on cover
SPECIFICATIONS
Inputs
PHONO 1-3
LINE 1-4, 4B, 5
MIC 5 symm.
Outputs
Master 1 symm.
Master 1-2 assymm.
Aux/FX-send assymm.
Recording 1-3
Aux
Phones
- Tone controls:
- Subsonic filter:
- Power source:
- Fuse:
- Power consumption:
- Approbation:
- Dimensions:
- Weight:
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
MODEL CX-1100
SERIAL NUMBER ................................. (on the back of the set)
Please give model and serial number when you request info.
Thank you very much for purchasing the RODEC mixing panel CX-1100.
This mixing panel is a topline mixing panel, capable of outstanding performance in combination with
high grade systems.
Input sensitivity Signal/Noise Ratio
2.3mV/50kΩ
220mV/50kΩ
3.5mV/3.3kΩ
3.3V/600Ω
1.55V/10kΩ
775mV/10kΩ
500mV/10kΩ
775mV/10kΩ
12V/600Ω
Bass +/-13dB @ 100Hz
Middle +/-13dB @ 1kHz
High +/-13dB @ 10kHz
-25dB @ 10Hz
Panels are leaving the factory on: 230V / 50Hz-60Hz
on request: 100V-117V / 50Hz-60Hz
T500mA
OFF=2.0VA
CE-approved
Front: 482mm x 310mm (19" x 7HE)
Chassis: 444mm x 295mm x 120mm
6.52kg
- 3 -
Remarks
< -77dB
< -90dB
< -85dB
Phones 200-600Ω
ON=34.5VA
- 2 -
- 3 -
- 3 -
- 4 -
- 5 -
- 6 -
- 26 -
RIAA correction
Subsonic filter
Subsonic filter
