PRODUCT OvERvIEW & OPERATIONS PRODUCT OvERvIEW & OPERATIONS
Air filter
Front panel
Vertical airflow
direction louver
• Do not adjust
by hand.
Horizontal airflow direction louver
• Manually adjustable.
• Be careful not to
insert your fingers
into the unit to
avoid injuring by
WARNING
cross-flow fan.
Remote
control
display

Auto OFF/ON button
• Used when remote control is misplaced or
malfunction.
Step
1
2
3
Press the button to turn off.
Receiver
TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote control
display to prevent the unit from starting / stopping improperly.
TO SET TEmPERATURE
• For heat, cool, and dry modes, the range of temperature for
selection is 16˚C ~ 30˚C.
• Operating the unit within the recommended temperature could
induce energy saving.
HEAT mode : 20˚C ~ 24˚C.
COOL mode : 26˚C ~ 28˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
TO SELECT OPERATION mODE
AUTO mode - For your convenience
• To set the temperature by pressing
• During Automatic Operation, the operation mode will be selected
automatically in accordance with the room temperature, outdoor
air temperature and set temperature of remote control.
• The operation mode changes every half hour if necessary.
(Example) Setting Temp at 25
36
32
25
HEAT
22
18
16
13
Outdoor Temperature
HEAT mode - To enjoy warm air
• Unit takes a while to warm up.
COOL mode - To enjoy cool air
DRy mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling operation.
Action
Press once.
Press and hold until 1 beep
is heard, then release.
Press and hold until you
hear double beep sound,
then release.
INDICATOR
(GREEN) (ORANGE) (RED)
or .
DRY COOL
19 21 23 25
mode
Auto
Force
Cooling
Force
Heating
(GREEN)
