200 207 C8 CF 78% 81%
208 215 D0 D7 82% 84%
216 223 D8 DF 85% 87%
224 231 E0 E7 88% 91%
232 239 E8 EF 91% 94%
240 247 F0 F7 94% 97%
248 255 F8 FF 97% 100%
Control-channel 22 - Switching the lamp, Reset, internal programs
Decimal Hexad. Percentage S/F
0 19 00 13 0% 7%
20 29 14 1D 8% 11%
30 39 1E 27 12% 15%
40 59 28 3B 16% 23%
60 79 3C 4F 24% 31%
80 84 50 54 31% 33%
85 87 55 57 33% 34%
88 90 58 5A 35% 35%
91 93 5B 5D 36% 36%
94 96 5E 60 37% 38%
97 99 61 63 38% 39%
100 119 64 77 39% 47%
120 139 78 8B 47% 55%
140 159 8C 9F 55% 62%
160 179 A0 B3 63% 70%
180 199 B4 C7 71% 78%
200 219 C8 DB 78% 86%
220 239 DC EF 86% 94%
240 255 F0 FF 94% 100%
Control-channel 23 - Pan-movement with 16 Bit-resolution
Control-channel 24 - Tilt-movement with 16 Bit-resolution
S Macro 25
S Macro 26
S Macro 27
S Macro 28
S Macro 29
S Macro 30
S Random CMY
S Normal colour-change, search position via shortest distance
S Color-change at every position, search position via shortest distance
S Color- and gobo-change at every position, search position via shortest
distance
S Lamp on
S Lamp off
S Reset all motors
S Reset only Pan/Tilt
S Reset only colors
S Reset only gobo
S Reset only shutter and/or dimmer
S Reset other motors
S Internal program 1 (Edit Program Scene 1 - 8)
S Internal program 2 (Edit Program Scene 9 - 16)
S Internal program 3 (Edit Program Scene 17 - 24)
S Internal program 4 (Edit Program Scene 25 - 32)
S Internal program 5 (Edit Program Scene 33 - 40)
S Internal program 6 (Edit Program Scene 41 - 48)
S Internal program 7 (Edit Program Scene 49 - 56)
S Music control
