5. Installation electrical

Separate the 12 V and 230 V supply from the
battery and the power mains.
Working on the electrical installation
without first separating the power
supply poses a mortal risk!
E1 Installing the base station
Select a suitable place for the installation of the
base station, e.g. in the seat or bed base, ideally
in immediate proximity of the drive units within a
minimum distance of 40 cm to the battery. The
base station can be installed on the floor or on the
wall.
Remove the housing cover of the base station by
removing the 2 screws holding it. Fasten the base
station using 4 screws. Drill 1 hole with a 25 mm
diameter at a distance of approx. 150 mm from
the base station into the vehicle bottom in order
to connect the motor cable. Ensure that there are
no installations or load-carrying parts in or under
the floor in the proximity of the hole. Duct the
cable through this hole.
E2 Connecting the drive motors
Lay the cables supplied with the left and right
drive unit to the base station. The cables are to be
connected to the motor according to the connec-
. Push the connections for the
tion diagram
base station through the respective hole from the
bottom.
Use the cable clamps supplied to lay and fasten
the cables. Mark the cable for the left and right
drive unit to ensure safe installation.
Always keep the cables for all drive units at the
same length. Avoid loops. Install the respective +
(plus) and - (minus) cable separately with a gap
between them, where possible.
Always keep the cable length as short as possi-
ble.
Cut the cables off at the right length as required
and remove approx. 5 cm of their insulation at the
ends. Fasten the cable shoes supplied with cable
shoe pliers.
Fasten the cables according to the connection
.
plan
Ensure good attachment!
Never lay the cables directly above the base sta-
tion or other electronic devices. They might get
damaged by strong magnetic fields during opera-
tion.
Caution:
Carefully seal the holes with suitable sealing ma-
terial from the inside and outside.
E3 Connecting the voltage supply
Lay the battery cable from the base station to the
battery. Please consider Point E4 (connecting the
main switch) in this context. The distance be-
tween the battery and the base station should
NEVER exceed the length of the cables supplied.
The shorter the cable, the better.
The strip fuse (150 A) installed in the plus (+)
cable must be located near the battery.
The fuse (150 A) must be replaced with an equiv-
alent fuse when it has been triggered.
Never swap the plus (+) and minus (-
) connection of the voltage supply!
E4 Connecting the main switch
The main switch in the battery cable is not re-
quired when a REICH MPP battery (Mobility Pow-
er Pack) is used. The MPP has a separate main
switch.
The main switch supplied is installed in the red,
plus (+) battery line. It must be easily accessible
from the outside. It is recommended to place it in
the area of the entrance door or a storage box
flap.
Cut the red, plus (+) cable for this purpose. Con-
nect the M10 ring cable shoes to the cut, un-
shielded cable by using appropriate pliers. Con-
nect the ring eyelets to the main switch.
Connect the battery cable to the battery. The
electrical installation is then complete.
