5 - ROUTINE MAINTENANCE

5.6 - Fuses replacement

1. Move the power switch to the OFF (O) position.
2. Unplug the power cord from the unit, and from the wall outlet.
3. Use a small flat screwdriver to gently push on the 2 small plastic clips on each side of the cable plug. These are fragile parts, take
care not to broke them!
4. Gently remove the fuse holder
5. Replace the 2 fuses with new 4 A fuses (see P10 for reference)
6. Put back the fuse holder
7. Plug in the unit and rock the power switch up to the ON (I) position.
8
Fig. 8 - ON/OFF switch / C14 Cable plug
Location of the fuse holder
Fig. 9 - Removed fuse holder
Gently push on the 2 small plastic
clips on each side of the cable plug
Fuses
