Install the Rails

1. Using measuring tape and pencil, mark the centerline of the
opening on the cabinet lower front wall.
2. Place the two rails inside the cabinet as shown below such
that distance between the nearest edges are 20
C
B
A. Cabinet
B. Rails
C. Side wall
3. Use a pencil to draw screw marks across six rails screw
holes C, D, E, F, G, H in the cabinet. Confirm that the
distance from hole D to centerline is 10
distance from hole F to centerline should be 10
(27.6 cm) as shown. Then take out of the two rails.
E
C
D
A. Cabinet
B. Rails
C. Hole C on left rail
D. Hole D on left rail
4. Using a 7/64" (2.8 mm) drill bit, drill four pilot holes C, D, F, G
on the cabinet lower front wall and two screw pilot holes E
and H inside the bottom of cabinet.
C D
B
A. Cabinet
B. Centerline
C. Pilot hole C
D. Pilot hole D
8
/ " (52.7 cm).
3
4
A
/ " (27.6 cm). Also,
27
32
/ "
27
32
A
H
B
F
G
E. Hole E on left rail
F. Hole F on right rail
G. Hole G on right rail
H. Hole H on right rail
A
E
H
F G
E. Pilot hold E
F. Pilot hole F
G. Pilot hole G
H. Pilot hole H
5. Put the two rails inside the cabinet, and align the screw holes
on rails and pilot holes on cabinet.
A
A. Cabinet
B. Rails
C. Holes on rails
D. Pilot holes on cabinet
6. Attach the two rails using the six #7-16x7/16" round-head
wood screws.
C
B
C
A. Cabinet
B. Rail (2)
C. #7-16x7/16" round head wood screw (6)
B
C
D
C
A
B
C C
