Symbol Designation
[Gross] display
[Selection] display
[Unit symbol] display
[Quantity]
[Invalid weight value]
display
4.4

Menu Structure

4.4.1

"Main Menu" Menu Structure

Navigating in menus (see Chapter 4 .5, page 15) .
t
Level 1 Level 2
SETUP BALANCE
GEN .SERV .
"General services"
DEVICE RS-232
"RS232, 9-pin"
USB
"USB-C"
EXTRAS
DATA .OUT . COM . SBI
"Data output" "SBI communication"
PRNT .PAR .
"Printout settings"
PC .DIREC .
"Direct transfer of data
(PC)"
Description
Indicates that a gross value is being displayed .
In the menu: Identifies the selected parameter .
If the "Calculation" or "Density determination" application is active: Indicates that a
calculated value is being displayed .
Indicates the set weight unit, e .g . [g] for "grams" .
Indicates that a quantity is being displayed .
− Indicates that the display does not contain a weight value, but is instead the
calculated result of an application, e .g . for the "Totalizing" application .
− For conformity-assessed devices: Indicates a fault . The cause of this fault is displayed
after pressing the [Change] key .
Description
Set the functions of the device .
Reset the menu to factory settings .
Define the parameters for the COM interface .
Define the parameters for the USB interface .
Define the functions of the operating display .
Configure the automatic data output .
Perform the settings for the printout .
Define the output format for the data exchange between the balance and
the PC .
Operating Concept
Entris ® BCE Operating Instructions 13
