Specifications, continued
BlueSolar charge controller
Battery voltage
Maximum battery current
Nominal PV power, 12V 1a,b)
Nominal PV power, 24V 1a,b)
Nominal PV power, 36V 1a,b)
Nominal PV power, 48V 1a,b)
Max. PV short circuit current 2)
Maximum PV open circuit voltage
Peak efficiency
Self consumption
Charge voltage 'absorption'
Charge voltage 'equalization' 3)
Charge voltage 'float'
Charge algorithm
Temperature compensation
Protection
Operating temperature
Humidity
Maximum altitude
Environmental condition
Pollution degree
Data communication port and
remote on/off
Parallel operation
Colour
PV terminals 3)
Battery terminals
Protection category
Weight
Dimensions (h x w x d)
Safety
1a) If more PV power is connected, the controller will limit input power.
1b) The PV voltage must exceed Vbat + 5V for the controller to start.
Thereafter the minimum PV voltage is Vbat + 1V.
2) A higher short circuit current may damage the controller in case of reverse polarity connection of
the PV array.
3) MC4 models: several splitter pairs may be needed to parallel the strings of solar panels
MPPT 150/85
12/24/48V Auto Select (36V: manual)
85A
1200W
2400W
3600W
4900W
70A
Less than 35mA @ 12V / 20mA @ 48V
Default setting: 14,4V / 28,8V / 43,2V / 57,6V
Default setting: 16,2V / 32,4V / 48,6V / 64,8V
Default setting: 13,8V / 27,6V / 41,4V / 55,2V
Multi-stage adaptive (eight preprogrammed
algorithms) or user defined algorithm
-16mV/°C / -32mV/°C / -48mV/°C / -64mV/°C
Battery reverse polarity (fuse, not user accessible)
Output short circuit / Over temperature
-30 to +60°C (full rated output up to 40°C)
95%, non-condensing
5000m (full rated output up to 2000m)
Indoor type 1, unconditioned
See the data communication white paper on our website
Yes (not synchronized)
ENCLOSURE
Blue (RAL 5012)
35mm² / AWG2 (Tr models),
or three pairs of MC4 connectors (MC4 models)
IP43 (electronic components)
IP 22 (connection area)
Tr models: 216 x 295 x 103mm
MC4 models: 246 x 295 x 103mm
STANDARDS
EN/IEC 62109-1 / UL 1741 / CSA C22.2 NO.107.1-16
MPPT 150/100
100A
1450W
2900W
4350W
5800W
70A
150V
98%
PD3
VE.Direct
35mm² / AWG2
4,5kg
