5. Specifications
BlueSolar charge controller
Battery voltage
Maximum battery current
Nominal PV power, 12V 1a,b)
Nominal PV power, 24V 1a,b)
Nominal PV power, 36V 1a,b)
Nominal PV power, 48V 1a,b)
Max. PV short circuit current 2)
Maximum PV open circuit voltage
Peak efficiency
Self consumption
Charge voltage 'absorption'
Charge voltage 'equalization' 3)
Charge voltage 'float'
Charge algorithm
Temperature compensation
Protection
Operating temperature
Humidity
Maximum altitude
Environmental condition
Pollution degree
Data communication port and
remote on/off
Parallel operation
Colour
PV terminals 3)
Battery terminals
Protection category
Weight
Dimensions (h x w x d)
Safety
1a) If more PV power is connected, the controller will limit input power.
1b) The PV voltage must exceed Vbat + 5V for the controller to start.
Thereafter the minimum PV voltage is Vbat + 1V.
2) A higher short circuit current may damage the controller in case of reverse polarity connection of the
PV array.
3) MC4 models: several splitter pairs may be needed to parallel the strings of solar panels
14
MPPT 150/45 MPPT 150/60
12/24/48V Auto Select (36V: manual)
45A
650W
1300W
1950W
2600W
50A
Less than 35mA @ 12V / 20mA @ 48V
Default setting: 14,4V / 28,8V / 43,2V / 57,6V
Default setting: 16,2V / 32,4V / 48,6V / 64,8V
Default setting: 13,8V / 27,6V / 41,4V / 55,2V
Multi-stage adaptive
(eight preprogrammed algorithms)
-16mV/°C / -32mV/°C / -48mV/°C / -64mV/°C
Battery reverse polarity (fuse, not user accessible)
Output short circuit / Over temperature
-30 to +60°C (full rated output up to 40°C)
95%, non-condensing
5000m (full rated output up to 2000m)
Indoor type 1, unconditioned
See the data communication white paper on our website
Yes, but not synchronized
ENCLOSURE
Blue (RAL 5012)
35mm² / AWG2 (Tr models),
or dual MC4 connectors (MC4 models)
35mm² / AWG2
IP43 (electronic components)
IP 22 (connection area)
Tr models: 185 x 250 x 95mm
MC4 models: 215 x 250 x 95mm
STANDARDS
EN/IEC 62109-1 / UL 1741 / CSA C22.2 NO.107.1-16
MPPT 150/70
60A
860W 1000W
1720W 2000W
2580W 3000W
3440W 4000W
50A
150V
98%
PD3
VE.Direct
3kg
70A
50A
