OPERATOR'S MANUAL
MANUEL D'UTILISATION
MANUAL DEL OPERADOR
5 cu. ft. (0.14 m
MÉLANGEUR DE BÉTON
DE 0,14 m
(5 cu. ft.)
3
MEZCLADORA DE HORMIGÓN
DE 0,14 m
(5 cu. ft.)
3
RMX001
TABLE OF CONTENTS
****************
Safety Warnings ..............................2-3
Safety Instructions ..........................3-4
 Symbols ..............................................5
 Electrical ..........................................6-7
 Features ..............................................8
 Tools Needed ..................................... 9
 Loose Parts List .................................. 9
 Assembly .....................................10-13
 Operation .....................................14-18
 Maintenance ..................................... 18
 Troubleshooting ............................... 19
 Parts Ordering / Service ..... Back Page
WARNING:
To reduce the
risk of injury, the user must read and
understand the operator's manual
before using this product.
SAVE THIS MANUAL FOR
FUTURE REFERENCE
) CONCRETE MIXER
3

TABLE DES MATIÈRES

 Symboles ............................................5
 Caractéristiques ................................. 8
 Outils nécessaires .............................. 9
 Liste des pièces détachées ................ 9
 Assemblage .................................10-13
 Utilisation .....................................14-18
 Entretien ...........................................18
 Dépannage .......................................19
 Commande de pièces /
réparation ......................... Page arrière
AVERTISSEMENT :
réduire les risques de blessures,
l'utilisateur doit lire et veiller à bien
comprendre le manuel d'utilisation avant
d'employer ce produit.
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE
****************
Pour
ÍNDICE DE CONTENIDO
****************
 Advertencias de seguridad
para herramientas eléctrica ............2-3
 Instrucciones de seguridad
de la mezcladora de hormigón .......3-4
 Símbolos ............................................5
 Aspectos eléctricos .........................6-7
 Características ................................... 8
 Herramientas necesarias .................... 9
 Lista de piezas sueltas ....................... 9
 Armado ........................................10-13
 Funcionamiento ...........................14-18
 Mantenimiento .................................. 18
 Solución de problemas .................... 19
 Pedidos de piezas /
servicio .......................... Pág. posterior
ADVERTENCIA:
el riesgo de lesiones, el usuario debe leer
y comprender el manual del operador
antes de usar este producto.
GUARDE ESTE MANUAL
PARA FUTURAS CONSULTAS
Para reducir
