Lenze 9400 Instructions De Montage page 51

Environmental conditions
Climate
Storage
Transport
Operation
Site altitude
Pollution
Vibration resistance
Transport
Operation
Assignment of filters to standard devices
DC power supply module
E94APNE1004
E94APNE2454
With RFI filters, EMC categories can be achieved.
With mains filters, EMC categories and a power increase P
With mains chokes, a power increase P
content). For adherence to EMC categories, additional further measures are necessary.
EDK94PNE245 DE/EN/FR/ES/IT 4.0
General data and operating conditions
IEC/EN 60721−3−1
IEC/EN 60721−3−2
IEC/EN 60721−3−3
EN 61800−5−1
2
(9.81 m/s = 1 g)
IEC/EN 60721−3−2
EN 61800−2
Germanischer Lloyd
IEC/EN 60068−2−6
Mains filter
(corresponds to "long
distance")
E94AZMP0824
E94AZMP2004
DC
l
Technical data
1K3 (−25 ... +60 °C)
2K3 (−25 ... +70 °C)
3K3 (−10 ... +55 °C)
Current derating from +45 ... +55 °C: 2.5 %/°C
0 ... 4000 m amsl
1000 ... 4000 m amsl: current derating of 5 %/1000 m
Degree of pollution 2
2M2
2 ... 9 Hz: Amplitude 3.5 mm
10 ... 200 Hz: acceleration resistant up to 10 m/s
200 ... 500 Hz: acceleration resistant up to 15 m/s
5 ... 13.2 Hz: Amplitude ±1 mm
13.2 ... 100 Hz: acceleration resistant up to 0.7 g
10 ... 57 Hz: Amplitude 0.075 mm
57 ... 150 Hz: Acceleration resistant up to 1 g
RFI filter
(corresponds to "short
distance")
E94AZRP0824
E94AZRP2004
can be achieved.
DC
is achieved (through reduction of the harmonic
4
2
2
Mains choke
EZAELN3080B371
EZAELN3200B151
51
