Moteur Libre, Sans Câbles; Raccordement Du Frein Et Des Microcontacts De Contrôle Du Frein - SMS TAKEDO-3VF TKP Manuel D'utilisation

Masquer les pouces Voir aussi pour TAKEDO-3VF TKP:
Table des Matières

Publicité

GUIDE RAPIDE DE MISE EN MARCHE
DES MOTEURS SYNCHRONES À AIMANTS
1 - RACCORDEMENT DU FREIN ET DES MICROCONTACTS DE
CONTRÔLE DU FREIN
(voir le Manuel TAKEDO-3VF NXP et l'Amendement 3)
R = 1,2k 1/4W
NOTER BIEN
La couleur des fils se réfère
aux moteurs SASSI
PRÉCABLÉS
MICRO CONTRÔLE
FREIN
PERMANENTS
MOTEUR LIBRE, SANS CÂBLES
Carte
NXOPTA1
BOBINE FREIN
TAKEDO - 3VF NXP MANUEL D'UTILISATION Version P07 du 23-05-2012
C
Carte
NXBR
(si présente)
TP, TP1
contacteurs
moteur
TABLEAU DE
MANŒUVRE
5
