GENERAL SAFETY PRECAUTIONS

This installation manual is intended for professionally competent
personnel only. Read the instructions carefully before beginning to
install the product. Incorrect installation may be a source of danger.
Packaging materials (plastic, polystyrene, etc.) must not be allowed
to litter the environment and must be kept out of the reach of children
for whom they may be a source of danger. Before beginning the
installation check that the product is in perfect condition. For repairs
or replacements of product only original spare parts must be used.
These instruction must be kept and forwarded to all possible future
user of the system.
1.

TECHNICAL DATA

Degree of protection IP43;
Temperature -20 °C / +55 °C
2. INSTALLATION
Properly fasten function selector close to the automation.
Note: function selector can be wall recessed on circular boxes,
we do not supply.
3.

ELECTRICAL CONNECTION

- Carry out the electrical connections as shown in fig. 1 or 2.
Up to a 5 m distance, and if no environmental disturbances are
present, the shielded cable need not be used. If the supplied
cable [A] is used, connected to the COM connector, terminals
0-1-21-22 are not to be connected to the electronic control
panel.
- With one single selector the same function modes can
be set in two different automations, by carrying out the
electrical connections shown in fig.5.
- The two selectors can be connected to one single
automation, as shown in fig.6.
- One or two selectors can be connected in order to set the
same function modes up to a maximum of four different
automations (not "redundant" type), as shown in fig.7.
Note: for electronic control panel networking, use the shielded
cable [F] for data transmission (we do not supply it), up to 1000
m total max length.
When selector manages more than two automations, cut the
resistor [X] in the intermediate electronic control panels (fig.7).
- The outlet connecting the automation to the personal
computer, through the DMCS software, can be accessed
by removing the selector cover (DMCS Jack – fig. 3). In
order to monitor and operate the automation via personal
computer, follow the instructions in the DMCS software
operating handbook.
3.1 Controls
Control
OPEN: it allows to open the automation in
any selector function mode.
1 OP Note: if the function mode selected is STOP,
the OPEN control triggers the delayed night
locking.
KEY: if the contact is opened , the selector
is disabled.
1 KEY
Attention: if a control (N.C.) is connected,
remove the jumper [P].
RESET: it eliminates the code set in the
RESET
selector.
Description
3.2 Settings
J1=ON
Delayed night locking
1 0 - s e c o n d b i - d i r e c t i o n a l
sequence.
J2=ON
Standard opening
Impulse OPEN control.
J3=ON
Code enabling
The access code can be set or
eliminated.
J4=ON
DMCS jack enabled
3.3 Signals
RED LED OFF
- The selector is working and no access code is
set.
RED LED ON
- The selector is protected by an access code.
- The selector is disabled.
RED LED FLASHING
- During setting and elimination of the access
code.
- At starting during the network learning phase
(30 s).
- The selector or another automation are not
recognized by the network (switch off and start
again repeating the learning phase).
3.4 TELRC infrared beam receiver
Remote adjustment of the electronic control panel settings (TC,
R1, etc.) can be carried out via the TEL2 radio remote control,
by installing the TELRC receiver inside the selector as shown
in the TELRC receiver handbook.
4. OPERATION
After having connected the selector switches and control panels,
turn on all control panels together and wait 30 s.
During the initial learning phase the padlock button red led
flashes and the 1-2-3-4 green leds light up depending on the
number of electronic control panels networked. If there are two
selectors networked the green led 6 lights up.
Operating modes are shown in the table on page 8.
7
J1=OFF
Delayed night locking
6 0 - s e c o n d b i - d i r e c t i o n a l
sequence.
J2=OFF
Emergency opening
If the OPEN button is held
pressed, the selector function
selector is set in the door open
mode.
Note: if the function mode
selected is STOP, the OPEN
control triggers the delayed
night locking.
J3=OFF
Code disabling
The access code can not be set
nor eliminated.
J4=OFF
DMCS jack disabled
