13 Difference measurement and Pass/Fail

36
You can compare the measurement
value of a sample with the target
value of a saved reference. You can
also display whether the test
specimen falls within the limits
(Pass) or outside (Fail).
Up to 50 references can be saved.
They are stored in a separate area
of memory. For each geometry you
can determine:
- The target value for the
difference
- Maximum and/or minimum for
Pass/Fail
The target value can also be set
equal to the maximum or minimum
value (see Create reference or
Change reference).
Difference
You can use this menu option to
turn Difference measurement on or
off. A check mark indicates if the
function has been activated.
When Difference is turned on, the
last reference to be used is
automatically selected.
