1
Description of the system
The reflectometer is a measuring
unit for determining the gloss of
paint coatings, plastics, ceramics
and metal surfaces.
Light is directed at the surface of
the sample at a defined angle and
the reflected light is measured
photoelectrically (reflectometer).
Depending on the typical gloss
level of the test object,
reflectometers that direct light onto
the surface at different angles
(geometry) can be used.
Measurement units are equipped
with standard geometries of 20°,
60° or 85°. All three of these
geometries are integrated into the
three angle device. Functions
described in this manual in terms of
geometry selection are only
available with the three angle
device.
In addition to measuring individual
gloss values, it is also possible to
record, save and statistically
evaluate series of measurements
consisting of up to 999 values.
12
The operate button and scroll
wheel are used to control the
system. System operation is
supported by display messages
(autodiagnosis and error
messages). You can select
German, English, French, Spanish,
Italian or Japanese (Katakana) as
the display language.
The measurement unit conforms to
the standards DIN 67530, ISO
2813, ASTM D 523 and BS 3900
Part D 5.
In addition, it was tested by the
"Bundesanstalt für Material-
forschung und -prüfung (BAM)"
(German Federal Institute for Mate-
rials Research and Testing) and
found to be properly categorized
and to meet requirements as set by
DIN 67530.
