KOBE CH9130SQB Manuel D'installation Et Mode D'emploi page 22

ORIGINAL KIT
NO. DESCRIPTION
01 Duct Cover-Mounting Bracket
02 Screw (TS 4 x 8 mm)
03 Duct Cover
04 Hood-Mounting Bracket
05 Screw (3/16" x 3/8")
06 Rubber Stand
07 Screw (TS 4 x 8 mm)
RECIRCULATING KIT
NO. DESCRIPTION
01 Duct Cover-Mounting Bracket
02 T-Head Box
A
Box
B
Box Bracket
03 Screw (TS 4 x 8 mm)
04 Recirculating Duct Cover
6" Round Plastic Exhaust
05
06 Aluminum Pipe
07 Charcoal Filter
Screw (3/16" x 1")
08
09 Hood-Mounting Bracket
Screw (3/16" x 3/8")
10
11 Rubber Stand
12 Screw (TS 4 x 8 mm)
(Optional Duct Cover)
MODEL /SIZE
RA1020DC
MODEL /SIZE
RA1020RD
20
PART NO.
C1-0203-0002
C1-0708-0006
12-02000-430-51
C1-0221-0330
C1-0707-0001
C1-0511-0201
C1-0708-0006
PART NO.
C1-0203-0002
C1-0241-1930-FA
C1-0241-1930-FB
C1-0708-0006
12-02000-430-51F
C1-0505-0001
C1-0601-0004
C1-0603-0302
C1-0707-0003
C1-0203-0330
C1-0707-0001
C1-0511-0201
C1-0708-0006
