Demounting of the drain level:
Pull the pusher (A) to the rearmost position (at the same time pulling the internal spring to back
1
to the end).
2
Pull lever (B) in the opposite direction
3
Remove the lever (B) by pulling it up:
B
3
2
Rotate the handle of the pusher and remove it:
The internal spring C with the seal A and pusher B can be removed from the cock pipe D:
A
B
C
D
E
The elements removed in the manner described above are ready for cleaning and disinfection.
The assembly of cleaned and disinfected elements is done in reversed order. When doing it, pay attention
to the following:
• Check whether the seal was correctly mounted on the container - if the seal does not adhere well
to the container, hot drinks may leak during the operation of the device, which can cause burns! Use
only water in order to settle the seal (do not use oils or greases).
• Ensure whether the container is appropriately mounted (clamps).
• Ensure that the shaft of the mixer is correctly settled.
• Check if the drain cock works properly and ensure that all elements are correctly settled.
16
1
A
DRAINER
The drainer must be emptied and cleaned each day. It must be emptied each time when the red floating
indicator is lifted up:
EMPTYING OF WATER CONTAINER
Before emptying the water contained disconnect the device from the power supply and empty the drink
container and wait until the device cools down.
To empty the water container, remove the lid of the container, place a vessel of a capacity of more than 3
litres under the drain hole and loosen the water drain screw:
The water container should be regularly decalcified using generally available agents
intended for decalcification of electric kettles, coffee machines, etc.

TRANSPORTATION AND STORAGE

Shaking, crashing and turning upside down of the device should be prevented when transported. Store it in a
properly ventilated surrounding with dry air and without any corrosive gas.

CLEANING AND MAINTENANCE

• Disconnect from electricity when cleaning equipment.
• Use cleaner without corrosive substances to clean surface.
• Dry all parts well after cleaning, before the device is used again.
• Store the unit in a dry, cool location, free from moisture and direct exposure to sunlight.
REGULAR CONTROL OF THE DEVICE
Control regularly that the device doesn´t present any damage. If it should be damaged, please stop using it
immediately and contact your customer service to solve the problem.
What to do in case of a problem?
Please contact your customer service and prepare following information:
• Invoice number and serial number (the latter is to be found on the technical plate on the device).
• If relevant, a picture of the damaged, broken or defective part.
•
It will be easier for your customer service clerk to determine the source of the problem if you give a
detailed and precise description of the matter. Avoid formulations like "the device doesn´t heat", which
may mean that it doesn´t heat enough or even not at all. Possibilities like these have different causes!
The more detailed your information, the better the customer service will be able to solve your problem
rapidly and efficiently!
CAUTION: Never open the device without the authorization of your customer service. This can lead to
a loss of warranty!
