Connection Type:
Warning
If you pay your bill according to the amount of time spent online, always select "Connect on Demand", so
that the connection to the internet is cut off on finishing and switching to "Idle Time".
Idle Time: Enter the length of time you want to wait before internet connection is cut off when inactive.
Important note for T-Online users:
The user name consists of: the 12-digit connection ID, T-Online number (if this is shorter than 12 digits, you
must complete it with the # symbol), 4-digit user number (e.g. 0001) and then @t-online.de. Enter all compo-
nents consecutively without spaces. The password is your T-Online access password.
Confirm with
The settings for signal transmission are entered using the above screen.
Then set the "ESSID". This is name for the Wireless LAN and can consist of up to 32 characters; It must be
the same for each device using the network. Under "Channel Number", select the channel you intend to use.
Click
Downloaded from www.Manualslib.com
12.02.2004 13:25 Uhr Seite 12
.
to confirm.
manuals search engine
We recommend always activating the encryption using the above screen. For key format enter "Hex
( 26 characters )". Settings must be identical for each device on the network. We recommend the use of
"Hex-Format" for key format. If possible use a 128 bit (58 hex characters 0-9, A-F and a-f) key (WEP128 Hex)
or 64 bit (10 Hex characters 0-9, A-F and a-f) key for configuration (WEP40 Hex).
Examples: 128 bit key "645645645ed354a354caef45ae"
64 bit key "da64650c4f".
After clicking once, the settings are accepted.
To leave router configuration, simply close your browser window.
This equipment may be operated only in Germany, Austria, Switzerland, France, England, Belgium, Spain, the
Netherlands, Italy, Denmark, Hungary, Poland, Sweden, Portugal, Luxembourg, Ireland, Greece and Finland.
See www.hama.de for the declaration of conformity with R&TTE Directive 99/5/EC
