QUICK START GUIDE
5
CONNECTING CABLES
8
MANAGING YOUR CABLES
1
UNPACKING
HDMI Cable DisplayPort Cable
USB Type-A to USB Type-C Cable
Type-B Cable
PGO32UFS PG Cable Sleeve
3
INSTALLING THE MONITOR STAND
UNLOCK LOCK
A B
6
CONNECTING THE MONITOR TO A PC
⚠
Notice: Use either the HDMI cable OR the DisplayPort cable for
connection to a computer.
9
POWERING ON
2
ATTACHING THE STAND BASE &
TIGHTENING THE SCREW
Power Cord
Wi-Fi Antenna Cables
QSG
Power Adaptor Quick Start Guide
4
I/O PORTS
1 2 3 4
7
CONNECTING ANTENNA CABLES BETWEEN
THE MONITOR AND THE ANTENNA PORTS ON PC.
10
-7 20
o
A
B
USB 3.2 Gen1 Type-B
1
Port (upstream)
USB 3.2 Gen1 Type-A
2
Port (downstream)
USB 3.2 Gen1 Type-A
3
Port (downstream)
USB 3.2 Gen1 Type-A
4
Port (downstream)
HDMI1 Input
5
6 HDMI2 Input
DisplayPort1 Input
7
8 DisplayPort2 Input
USB 3.2 Gen1 Type-C
6 9
Port (DP Alt Mode/PD 65W)
10 USB Port (firmware update)
11 Audio Ouput
DC-IN Port
12
5 6 7 8 9 10 11 12
ADJUSTING THE TILT, SWIVEL & HEIGHT
ANGLE
o
20
o
100mm
20
o
