COMPLYING WITH THE NEW EUROPEAN RULES, GIMA S.p.A. INDICATES THE IMPORTANT POINTS TO PROTECT INSTRUMENT AND
OPERATORS HYGIENE.
THESE RULES MUST BE RESPECTED IN ORDER TO GUARANTEE HYGIENE AND SAFETY TO ALL THE PEOPLE OPERATING WITH THE
INSTRUMENT TO OBTAIN QUALITY AND WELL BEING.
Every returned instrument will be hygienically checked before repairing. If GIMA finds instrument not suitable for repairing due to clear signs of internal or
external contamination, the same will be returned to customer with specification of NOT REPAIRED INSTRUMENT, accompanied by an explanation
letter.
GIMA will decide if contamination is due to bad functioning or misuse. If contamination is due to bad functioning, GIMA will substitute the instrument, only
if a SALE RECEIPT and STAMPED GUARANTEE accompany the same.
GIMA is not responsable for contaminated accessories, they will be substitute at customer's expenses.
For this reson it is COMPULSORY to carefully disinfect the external part of the instrument and accessories with a cloth soaked in methylated spirits or
hypochlorite-based solutions. Put the instrument and accessories in a bag with indication of disinfecting.
We also request to specify the kind of fault, in order to speed up repairing procedures.
To this end, please read the instructions carefully in order to avoid damaging the equipment through improper use.
Always specify the fault encountered so that GIMA can establish whether it falls into the category of the faults covered by the guarantee.
The SUPER VEGA BATTERIA suction equipment does not need maintenance or lubrication.
It is necessary to check functioning and instrument before every use. Unpack the instrument and always check integrity of plastic parts and feeding
cable, they might have been damaged during previous use. Connect cable to electrical network and turn switch on.
Close the aspirator outlet with your finger and with suction regulator in maximum vacuum position check that the vacuum indicators reaches
– 75 kPa (-0.75 bar) minimum (internal battery). Rotate the knob from right to left and check the aspiration regulating control.
The vacuum indicator should go down – 40 kPa (-0.40 bar). Verify that loud noises are not present, these can indicate wrong functioning.
The equipment may also be used with the power cord hooked up to the electricity mains (the yellow light switches over to the fixed green light).
Ensure that the green light comes on and that, after a few seconds it switches over to the yellow light (meaning that the charged battery is operating).
A protection fuse (F 1 x 630mA 250V) reachable from exterior and it situated in the plug protects the instrument.
For fuse replacing, always the type and the range.
The device is made up of a lead battery which cannot be accessed by outside. In order to replace it, consult the technical staff authorised by the
manufacturer.
Fault type
1. Red light on
2. Red light on
3. No aspiration
4. No aspiration
5. The float doesn't close
6. The float doesn't close
7. Low suction
8. No aspiration due to flow
leakage of mucus
Faults 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8
If the overfill security system it's activated, don't proceede with the liquid aspiration.
If the overfill security system doesn't work there are two cases:
1° case – If the overfill security system doesn't work the aspiration will be stopped by the bacteriological filter who avoid the liquid penetration inside the
device.
2° case – If both the security system doesn't work, there is the possibility that liquid comes inside the device, in this case return the device to GIMA S.p.A.
technical service.
The manufacturer will provide upon request electric diagrams, components list, descriptions, setting instructions and any other information
that can help the technical assistance staff for product repair.
BEFORE EVERY CHECKING OPERATION, IN CASE OF ANOMALIES OR BAD FUNCTIONING, PLEASE CONTACT GIMA S.p.A.
GIMA S.p.A. DOES NOT GIVE GUARANTEE IF INSTRUMENT, AFTER THE TECHNICAL SERVICE CHECKING, APPEARS TO BE
RULES FOR RETURNING AND REPAIRING
MAINTENANCE
Cause
Battery run down
Battery run down
Jar Cap badly screwed down
Lid seal not in its seat
If the cap has been washed, ensure
that the float is not partially detached
The float it's covered by dirty material
Foam inside the jar
Filter blocked
None of the remedies has
achieved the desired results
TECHNICAL SERVICE.
Hook up the power cord to the electricity mains, positioning the
equipment power switch on 0. Charge it for 8 hours, until the yellow
light switch over to the green light.
The device may be also be supplied by an power cord hooked up
to the electricity mains: the yellow light comes on and then switch
Unscrewed the cap, then rescrew it correctly
Unscrew the cap and insert the seal properly in its seat
Insert the float into it's place
Unscrewed the cap, leave the and put in on autoclave
Fill the jar to 1/3 full of ordinary water
Contact the seller or GIMA After-sales Assistance Service
TAMPERED.
11
Solution
over to the green light.
Replace filter
