Daily openings
4
10
20
The package includes a cable that can be used to connect the power supply of SOLO EVO. The supplied cable
has a length of 4 meters and is resistant to water and atmospheric agents, therefore it can be used outdoors.
The wide supply voltage range accepted by SOLO EVO makes it possible to connect to the power supply provi-
ded by most of the control units for gates and garages.
Once the power cable has been inserted and connected, secure it using the small strap supplied and close the
device using the 4 screws supplied.
Date and time
SOLO is equipped with an internal clock that is used to check the users' access time rights. The internal clock
manages the European daylight saving time independently. The date will be set automatically by the app at the
Average duration
48 months
24 months
12 months
SOLO EVO: battery power supply selection
To power SOLO EVO using batteries, set the jumper selector
on the board to the "BT" position and remove the battery pro-
tection tab. Close the device using the 4 screws provided in
the package.
SOLO EVO: 12-24V AC/DC power supply selection
To power SOLO EVO through an external 12-24V source it is
necessary to set the jumper selector on the board to the "AL"
position.
SOLO EVO is equipped with an already mounted IP66 cable
gland that must be used to route the power cable. It is neces-
sary to remove the batteries and puncture the cable gland with
a small screwdriver before inserting the power cable.
Then connect the power supply to the screw terminal block,
taking care to respect the indicated polarity.
