16
Energy meter failure
17
Fuse tripped
18
DC RCD tripped
19
Relay error detected
20
Card identifier expired
21
Connector was discon-
nected and reconnected
again
22
An over-current event
has occurred
23
Master slave watchdog
timeout occurred
24
RFID reader failed
25
Charger blocked due to
log full
26
Alarm sensor tripped
27
Emergency switch acti-
vated
28
DC charger error
29
Too many state changes,
charger stopped
30
German Eichrecht error
31
Supervisor warning
14.
www.ecotap.nl
Check that the Energy Meter works well
Check the Modbus configuration (controller, Meter)
Check the RS485 cabling inside the charger
Check the presence of the 120 Ohms resistors (one on controller side,
one on terminal block OR meter side)
Replace the Energy Meter by an Ecotap spare part
Check the current configuration according to the protection (taking into
account temperature derating)
Replace Fuse by MCB (C40 curve C 10000/16kA) by an Ecotap spare
part
Not issued anymore
Check the contactor
Check the auxiliary on the contactor
Check the integrity of the cable from the contactor to the controller
Check the integrity of the cable from the contactor auxiliary to the
controller
Replace the contactor and the auxiliary by an Ecotap spare part
The tag pass is not accepted by the backend
Check the current absorb by the EV
Check the CANBus connection between the different charger
Check the presence of the 120 Ohms resistors on the first and last
charger (Master and last slave)
Check the configuration
Check the RFID reader integrity
Check the integrity of the cable from the RFID Reader to the controller
Replace the RFID reader by an Ecotap spare part
Clean the log
Check the door sensor
Check the integrity of the cable from the door sensor to the controller
Replace the door sensor by an Ecotap spare part
Check the emergency switch
Check the integrity of the cable from the emergency switch to the
controller
Replace the emergency switch by an Ecotap spare part
Check the configuration link to the current management according to
the available current
Stop and start a new transaction
12-03-25
