Caution: Static electricity can damage circuit boards.
• Use proper precautions when handling printed circuit boards.
– Store PC boards in anti-static containers.
– Wear a grounded wrist strap when handling PC boards.
Introduction
Purpose
This Field Service Bulletin describes the procedure for replacing the power switch on a Powermax65 or Powermax85.
Materials and tools
®
• Assorted Phillips and TORX
• Small knife or blade screwdriver
Kit 228644 contents (Powermax65 CSA)
Part number Description
005257 Power switch: 3-pole 600VAC 40A with auxiliary switch
075760 Plastite machine screw
108858 Handle: G4 CAM switch "I" type
110711 Label: Power switch 65A/85A
Field Service Bulletin
Powermax65/85 Power Switch rePlacement
Disconnect electrical power before performing any maintenance. See the
Safety and Compliance Manual included with your system for more safety
precautions.
®
screwdrivers
WARNING
ELECTRIC SHOCK CAN KILL
Quantity
1
4
1
1
1
