Connecting the LED Wires Directly
If you do not install the recommended remote control, you can set the static color and tone of the LEDs by
connecting specific color LED wires from the harness to the negative (-) terminal of a 12 Vdc power source.
You must connect only the dark blue LED wire from the harness to the positive (+) terminal of the same power
source to complete the circuit.
You must use the provided harnesses when connecting the LED wires directly to power.
You should use 20 AWG (0.5 through 0.75 mm
the battery.
You must connect the positive (+) wire (dark blue) for all of the speaker LED harnesses through an appropriately
rated fuse (not included) near the power-source. You should also connect the positive (+) wire to the power
source through an isolator switch or circuit breaker to turn the LEDs on and off. You can use the same isolator
or circuit breaker controlling the power supply to your stereo, which allows you to turn the LEDs and the stereo
on and off at the same time.
You should use a water-tight connection method when connecting wire to the LED wiring harness.
1 Connect the negative (-) wire from the same power source to the color wires on the LED harness according
to the preferred LED color.
To prevent property damage or personal injury, you must insulate any unused LED wires on the harness to avoid
causing a short circuit.
Wire Color
Dark blue
Black/light green
Black/red
Black/green
Black/light blue
Black/yellow
NOTE: Individual colors can be combined to create new LED color tones if you are not using an LED
controller.
2 Connect the dark blue wire on the LED harness to the positive (+) terminal of the power source .
To avoid damage to the speakers or the vessel, you must connect the dark blue positive wire through an
appropriately rated fuse (not included) near the power source.
3 Connect the harness to the speaker.
6
2
) or thicker wire to connect the LED wires from the harness to
WARNING
Wire Use
LED power (+VE)
Cool white LED (-VE)
Red LED (-VE)
Green LED (-VE)
Blue LED (-VE)
Warm white LED (-VE)
NOTICE
