Menu Parameters
The Main menu organizes the available transmitter parameters into three
categories:
• Radio
• Audio
• Utilities
Radio
Tips for Editing Menu Parameters
• To access the menu options from the home screen, select enter.
Select enter again to access the menu parameters.
• A menu parameter will blink when editing is enabled
• To increase, decrease or change a parameter, use the arrow buttons
• To save a menu change, select enter
• To exit a menu without saving a change, select exit
Menu Map
Main Menu
Main
Radio
Freq
Power
Output
Audio
O set
Mute
Tone Gen
Utilities
Device ID
Locks
Marker
Battery
About
Reset All
Menu Parameter Descriptions
Radio Menu
Freq
Press the enter button to enable editing of a group (G:) channel (C:)
or frequency (MHz). Use the arrow buttons to adjust the values. To edit
the frequency, press the enter button once to edit the first 3 digits, or
twice to edit the second 3 digits.
Power
Higher RF power settings can extend the range of the transmitter.
Note: Higher RF power settings decrease battery runtime.
Output
Sets the RF output to On or Mute.
- On: RF signal is active
- Mute: RF signal is inactive
Audio Menu
Offset
Adjust Offset level to balance mic levels when using two transmitters
or when assigning multiple transmitters to receiver slots. Adjustment
range: -12 dB to +21 dB.
Mute
When enabled, the power switch is configured as a mute switch for the
audio:
- Power switch on: Audio signal on
- Power switch off: Audio signal muted
Exit mute mode to return the power switch to its normal functionality.
Tone Gen
Transmitter will generate a continuous test tone:
- Freq: The tone can be set to 400 Hz or 1000 Hz.
- Level: Adjusts the output level of the test tone.
Utilities Menu
Device ID
Assign a device ID of up to 9 letters or numbers.
Locks
Locks the transmitter controls and power switch.
- None: The controls are unlocked
- Power: The power switch is locked
- Menu: The menu parameters are locked
- All: The power switch and menu parameters are locked
Marker
When enabled, press the enter button to drop a marker in Wireless
Workbench.
Battery
Displays battery information:
- Battery Life: Runtime reported in bar display and time (hours:minutes)
- Charge: Percentage of charge capacity
- Health: Percentage of current battery health
- Cycle Count: Total of the number of charging cycles for the installed battery
- Temperature: Battery temperature reported in Celsius and Fahrenheit
About
Displays the following transmitter information:
- Model: Displays the model number
- Band: Displays the tuning band of the transmitter
- FW Version: Installed firmware
- HW Version: Hardware version
- Serial Num: Serial number
Reset All
Restores all transmitter parameters to factory settings.
