ENGLISH
The LINEAR automation system for swing gates comprises an
electromechanical operator which drives the gate leaves by
means of a worm screw.
The LINEAR operator is irreversible and locks mechanically when
the motor is not in use. Therefore a lock does not need to be fitted.
Its manualoveride is activated by a customised key.
The LINEAR automated systems were designed and manufactured
to control access of vehicles. Avoid any other use whatever.
1. DESCRIPTION AND TECHNICAL SPECIFICATIONS
Fig. 1
5
1
2
Table 1: Operator technical specifications
Model
Power supply
Absorbed power
Current drawn
Electric motor rpm
Thermal cutout
Capacitor
Max. thrust/traction force
Rod stroke
Rod speed
Temperature range
Operator weight
Housing protection
Duty cycle (cycles/hour)
Maximum leaf length
2. STANDARD INSTALLATION LAYOUT
1) Operators
2) Photocells
3) Control unit
4) Keyswitch
5) Receiver
6) Flashing light
Notes:1) Use suitable rigid/flexible pipes for laying power cables.
2) Always keep low voltage accessory cables separate from 230V~ power
cables. To avoid interference, use separate sheaths.
LINEAR AUTOMATION
4
3
1) Motor Unit
2) Power cable
3) Worm screw
4) Front bracket
5) Rear bracket
LINEAR
LINEAR
24
230V~ - 50Hz 24Vdc 230V~ - 50Hz
350W 70W
1,5A 3A
1400
140°C
10 µF / 400V 8 µF / 400V
400 daN 300 daN 320 daN
300 mm / 400 mm
1,6 cm/sec 1,1 cm/sec
-20°C +55°C
6,5 Kg
IP 44
20 50
3 m / 4 m
Drawing A
Table A: Recommended dimensions (in mm)
Model
300
LINEAR
400
LENTO
(¹) useful rod stroke
280W
CALCULATING INSTALLATION DIMENSIONS:
1,2A
900
If the dimensions specified in Table A cannot be used,
140°C
calculate different dimensions as follows:
- For 90° leaf opening: a + b = c
- For leaf opening over 90°: a + b < c
400 mm
- The lower the dimensions of a and b the higher the
gate speed. Ensure that current standards are
observed.
- Make sure that the difference between a and b is
no more than 4 cm: larger differences cause large
variations in speed during opening and closing.
- Due to the dimensions of the operator, the minimum
20
value for Z is 65 mm (fig. A)
If the dimensions of the gate post or the position of
the hinge do not allow a to be kept within the
required value, make a recess in the gate post as
shown in fig. B.
Fig. 2
4
INSTALLATION DIMENSIONS
B
65 min.
α α α α α
A B C (¹)
90° 145 145 290
110° 125 125 290
90° 195 195 390
110° 165 165 390
(²) max. dimension (³) min. dimension
GENERAL RULES
Fig. A
D (²) Z (³) L
70 65 970
50 65 970
120 65 1170
90 65 1170
Fig. B
