Installation Instructions
Installing the Drawer Handles
The following instructions for installing the drawer handles apply only for the models, PRRFD24C2AS.
The contemporary handles replacement part number per handle is 50280011, and the part number
for each pro handle is 50280012.
1. Secure (4) handle screws onto
the drawers.
Installing the Drawer Handles and Overlay Panel
Set Screw
Drawer handles are not included with the panel ready model, PRRFD24C2AP. You may choose your
own handles that match your cabinetry, or you may purchase Zephyr contemporary or pro handles.
The part numbers are listed below.
Set Screw
NOTE: These handles are not compatible with PRRFD24C2AS.
18
Zephyr Presrv Contemporary Handles
Part #: PRHAN-C101
Part #: PRHAN-C102
Part #: PRHAN-C104
Zephyr Presrv Pro Handle
Part #: PRHAN-C001
Refrigerator Freezer Drawers Use, Care, and Installation Guide
Set Screw
Set Screw
2. Install handles onto the
drawers. Using the hex key,
tighten the (2) set screws on
the bottom of each panel.
Color: Stainless Steel
Color: Brushed Gold
Color: Matte Black
Color: Stainless Steel
P R E S R V ™
R E F R I G E R ATO R
F R E E Z E R D R AW E R S
D U A L Z O N E
