Dimensions:
millimeters (inches)
Model No.
LT15
LT60
LT150
LT300
LT400
LT600
(LT600-FR-F-*-*)
LT800
LT1500
* LT1500 includes 4 feet on base, add 20 mm (3/4") to D for full height.
LT1500 is fitted with carry handles - not shown on diagram.
A
6
A
B
37 (1-1/2")
136 (5-3/8")
62 (2-1/2")
190 (7-1/2")
62 (2-1/2")
190 (7-1/2")
62 (2-1/2")
190 (7-1/2")
62 (2-1/2")
190 (7-1/2")
62 (2-1/2")
212 (8-3/8")
100 (4")
212 (8-3/8")
100 (4")
212 (8-3/8")
140 (5-1/2")
260 (10-1/4")
E
B
Note: LT15 has only one pressure/temp connection
C
D
37 (1-1/2")
115 (4-1/2")
50 (2")
121 (4-13/16")
50 (2")
121 (4-13/16")
50 (2")
122 ( 4-13/16")
50 (2")
122 ( 4-13/16")
75 (3")
139 ( 5-1/2")
75 (3")
139 ( 5-1/2")
75 (3")
139 ( 5-1/2")
100 (4")
161 ( 6-3/8")*
One M16 x 2 test point fitted as
standard (not shown)
Pressure/temp connector
M10 Port
E
Weight kg (lbs)
69.5 (2-3/4")
0.7 (1.5)
103 (4")
1.6 (3.5)
103 (4")
1.6 (3.5)
103 (4")
1.7 (3.7)
103 (4")
1.7 (3.7)
127 (5")
2.7 (6)
126 (5")
5.0 (11)
126 (5")
5.0 (11)
130 (5-1/8")
10.0 (22)
D
C
