maintenance
EN
5.4
door trim removal
To remove, slide the back edge of the door trim up and out of the glass and the door frame.
To install, slide the back edge of the door trim down between the glass and door frame. Insert downwards.
5.5
fi rebox glass door removal
Leave a hand on the glass door during entire door removal. The glass door is secured to the fi rebox with four
(BL42) or eight (BL56) spring latches. Pull the handles of the latches forward, then lift the latches out from the door
frame to release the door. Next, lift the door up until the bottom edge clears the bottom shoulder screws of the
appliance. Carefully grip the top and bottom of the door lifting it off the appliance.
note:
These spring latches
make up the spring
relief system for the
appliance. Ensure the
door opens freely and
closes sealed.
note:
When mounting the door,
ensure there is equal
space on both the left and
the right side. This allows
for easy installation of the
front.
Reverse these steps to reinstall the door. Ensure safety screen is installed correctly.
20
W415-3038/ 05.05.21
BL56 illustrated
