ENGLISH – Rolling screen installation and operation manual
Ensure that the screen has suffered no damage during transport. Should any fault be detected, promptly notify your dealer. Verify that all screen accessories have been included
Rolling screen UNDER 510 cm width
-2 installation brackets
-3 screws per bracket
-1 10° unipolar, 250V dead man's selector switch with directional
arrows, inclusive of wall mount hood
-1 plastic hex wrench
-1 instructions booklet
(screws and plugs for wall mount are not included)
ATTENTION do not use cutters or sharp objects to open the wrapping, always use protection gloves when unpacking, handling and installing the product. Depending on the product's weight (reference load:
25 Kg male – 15 Kg female), handling and installing operations should be performed by two, three or four people at least. For heavier loads we recommend the use of specific lifting equipment.
Remove the screw wich fix the Velcro and remove it from the case:
Made by Adeo Screen sp. Z o.o. (Poland) Specifications are subject to change without notice. E&OE
Doc: MAX ONE Installation Manual rev9 |25.02.2025
Please verify that you are working with the latest revision of this document before specifying your screen.
06 UNPACKING AND HANDING THE SCREEN
Rolling screen OVER 510 cm width and UNDER 610 cm
-3 installation brackets
-3 screws per bracket
-1 10° unipolar, 250V dead man's selector switch with directional
arrow, inclusive of wall mount hood
-1 plastic hex wrench
-1 instructions booklet
(screws and plugs for wall mount are not included)
Rolling screen OVER 610 cm width
-4 installation brackets
-3 screws per bracket
-1 10° unipolar, 250V dead man's selector switch with
directional arrow, inclusive of wall mount hood
-1 plastic hex wrench
-1 instructions booklet
(screws and plugs for wall mount are not included)
Page 4
