CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-445-1527 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m.
Page 2
Table of Contents Assembly Tools Required Part Identification No. 2 Phillips Screwdriver Hardware Identification Tip Shown Actual Size Hardware Usage Guide Assembly Steps 7-32 Hammer Not actual size Français 33-36 Español 37-40 Safety 41-42 Adjustable Wrench Warranty Page 2 www.sauder.com/service 429514...
Page 3
RIGHT BACK (1) DRAWER BOTTOM (2) TOP (1) UPPER DRAWER FRONT (1) DRAWER BRACE (2) BOTTOM (1) LEFT DRAWER SIDE (2) LOCK DRAWER FRONT (1) SKIRT (1) UPPER RIGHT DRAWER SIDE (1) LOWER RIGHT DRAWER SIDE (1) 429514 www.sauder.com/service Page 3...
Page 5
PLATE - 2 BRACKET - 2 1-1/2" FLAT HEAD SCREW - 10 7/8" MACHINE SCREW - 2 SILVER 1/2" PAN HEAD SCREW - 9 BLACK 1/2" PAN HEAD SCREW - 20 3/8" PAN HEAD SCREW - 24 429514 www.sauder.com/service Page 5...
Page 6
The arrow in the HIDDEN CAM must point Arrow toward the hole in the edge of the board. Hidden Cam Hole Insert the CAM SCREW or CAM DOWEL into the HIDDEN CAM. Tighten the HIDDEN CAM. Page 6 www.sauder.com/service 429514...
Page 7
Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Page 8
NOTE: The EXTENSION SLIDES will be used later for the DRAWERS. Open end Push the black lever and pull the SLIDE from the RAIL. Use these holes. 3/8" PAN HEAD SCREW (6 used in this step) These holes Open end must be here. Page 8 www.sauder.com/service 429514...
Page 9
Step 3 å Push thirteen LARGE HIDDEN CAMS (7) into the BACKS (F and G). å Turn seven CAM SCREWS (9) into the exact holes shown in the BACKS (F and G). Arrow (13 used) Arrow Arrow 429514 www.sauder.com/service Page 9...
Page 10
Fasten the LEFT BACK (F) to the RIGHT BACK (G). Tighten three HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the LEFT BACK insert into the RIGHT BACK. These CAM SCREWS must be here. Page 10 www.sauder.com/service 429514...
Page 11
SKIRT (E). å Insert two LARGE WOOD DOWELS (13) into the SKIRT (E). å Fasten the BOTTOM (D) to the SKIRT (E). Tighten three HIDDEN CAMS. (15 used) Arrow Arrow Arrow Arrow These surfaces should be even. 429514 www.sauder.com/service Page 11...
Page 12
Fasten the BOTTOM (D) to the BACKS (F and G). Tighten four HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the BACKS insert into the BOTTOM. i t h f a c S u r D E N H I D Page 12 www.sauder.com/service 429514...
Page 13
LEFT BACK (F). Tighten seven HIDDEN CAMS. you do something else. å NOTE: Be sure the WOOD DOWELS in the END insert into the BOTTOM and BACK. To help line up holes, place packing foam or books here. 429514 www.sauder.com/service Page 13...
Page 14
Step 8 å Push three LARGE HIDDEN CAMS (7) into the RIGHT END (B). å Turn seven CAM SCREWS (9) into the exact holes shown in the RIGHT END (B). Arrow Page 14 www.sauder.com/service 429514...
Page 15
RAIL in to find the other holes that line up with the holes in the END. Turn a SCREW into each hole. Open end Use these holes. Open end 3/8" PAN HEAD SCREW (6 used in this step) 429514 www.sauder.com/service Page 15...
Page 16
Fasten the INTERLOCK MECHANISM (10) to the RIGHT END (B). Use three SILVER 1/2" PAN HEAD SCREWS (16). SILVER 1/2" PAN HEAD SCREW (3 used for the MECHANISM) BLACK 1/2" PAN HEAD SCREW (2 used for the BRACKET) Page 16 www.sauder.com/service 429514...
Page 17
å Fasten the RIGHT END (B) to the BOTTOM (D), SKIRT (E), and RIGHT BACK (G). Tighten seven HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the END insert into the BOTTOM and BACK. 429514 www.sauder.com/service Page 17...
Page 18
BLACK 1/2" PAN HEAD SCREWS (24). å Fasten two LARGE BRACKETS (20) to the ENDS (A and B) and SKIRT (E). Use four BLACK 1/2" PAN HEAD SCREWS (24). BLACK 1/2" PAN HEAD SCREW (8 used in this step) Page 18 www.sauder.com/service 429514...
Page 19
å Fasten the TOP (C) to the ENDS (A and B) and BACKS (F and G). Tighten ten HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the TOP insert into the ENDS and BACKS. 429514 www.sauder.com/service Page 19...
Page 20
3/8" PAN HEAD SCREW (12 used for the SLIDES) SILVER 1/2" PAN HEAD SCREW (6 used for the ACTUATORS) Open end The large holes are closer to this edge. Open end The open end will overlap this edge. Page 20 www.sauder.com/service 429514...
Page 21
NOTE: Be sure the WOOD DOWELS in the DRAWER SIDES insert into the DRAWER BACK. å Repeat this step for the other drawer. Groove (8 used in this step) 1-1/2" FLAT HEAD SCREW (8 used in this step) 429514 www.sauder.com/service Page 21...
Page 22
Step 16 å Slide the DRAWER BOTTOM (M) into the grooves in the DRAWER SIDES (J and K) and DRAWER BACK (L). å Repeat this step for the other drawer. Page 22 www.sauder.com/service 429514...
Page 23
Fasten the DRAWER BRACE (N) to the DRAWER BACK (L). Use one 1-1/2" FLAT HEAD SCREW (21). This hole must be here. (2 used in this step) 1-1/2" FLAT HEAD SCREW (2 used in this step) 429514 www.sauder.com/service Page 23...
Page 24
NOTE: You should start each SCREW a few turns before completely tightening any of them. å Repeat this step for the other drawer. (10 used in this step) BLACK 1/2" PAN HEAD SCREW (8 used in this step) The open channel should be here. Page 24 www.sauder.com/service 429514...
Page 25
FRONT (H). Use one 7/8" MACHINE SCREW (22). å Repeat this step for the other drawer. NOTE: Be sure the small pin in the KNOB inserts into the small hole in the DRAWER FRONT. 7/8" MACHINE SCREW (2 used in this step) 429514 www.sauder.com/service Page 25...
Page 26
Repeat this step for the other drawer. Be sure the DRAWER BOTTOM inserts into the DRAWER FRONT groove. (10 used in this step) (10 used in this step) Arrow For support, place packing foam or books here. Page 26 www.sauder.com/service 429514...
Page 27
Step 21 å Fasten the DRAWER BRACKET (18) to the UPPER RIGHT DRAWER SIDE (K) exactly as shown. Use two BLACK 1/2" PAN HEAD SCREWS (24). BLACK 1/2" PAN HEAD SCREW (2 used in this step) 429514 www.sauder.com/service Page 27...
Page 28
Step 22 å Fasten the LOCK PACK (23) to the LOCK DRAWER FRONT (P) exactly as shown using your Adjustable Wrench to tighten the nut around the lock. Front Back Locked Unlocked Page 28 www.sauder.com/service 429514...
Page 29
Press a LONG FILE GLIDE (3) onto the DRAWER BACK (L). Almost time to å Press two SHORT FILE GLIDES (4) onto the celebrate! With a nap. DRAWERS SIDES (J and K). å Repeat this step for the other drawer. 429514 www.sauder.com/service Page 29...
Page 30
Place the FILE BARS (6) onto the FILE GLIDES (3 and 5). å Repeat this step for the other drawer. L e t t e r L e g t e r L e t t e r L e t Page 30 www.sauder.com/service 429514...
Page 31
Diagram 4. Push the drawer in until it is fully inserted. Pull the lower wing forward until it clicks into place. The Lower Drawer ACTUATOR must be here. Pull the upper wing forward until it clicks into place. 429514 www.sauder.com/service Page 31...
Page 32
NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or 35 lbs. each Page 32 www.sauder.com/service...
Page 33
DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en EXTRÉMITÉ GAUCHE ..........1 (ENSEMBLE DE GLISSIÈRE ILLUSTRÉ À PART) ce qui concerne cet GLISSIÈRE D'EXTENSION ........4 EXTRÉMITÉ DROITE ..........1 élément, faire référence COULISSE D'EXTENSION ........4 DESSUS ................1...
Page 34
Faire tourner sept VIS D'EXCENTRIQUE (9) dans les trous exacts illustrés de l'EXTRÉMITÉ DROITE (B). Enfoncer treize GRANDES EXCENTRIQUES ESCAMOTABLES (7) dans les ARRIÈRES (F et G). Faire tourner sept VIS D'EXCENTRIQUE (9) dans les trous exacts illustrés dans les ARRIÈRES (F et G). Page 34 www.sauder.com/service 429514...
Page 35
REMARQUE : S’ a ssurer d’insérer les CHEVILLES EN BOIS du DESSUS dans les EXTRÉMITÉS et les ARRIÈRES. ÉTAPE 19 Fixer un BOUTON (12) sur le DEVANT DE TIROIR SUPÉRIEUR (H). Utiliser une VIS À MÉTAUX 22 mm (22). Répéter cette étape pour l'autre tiroir. 429514 www.sauder.com/service Page 35...
Page 36
VIS visible et EXCENTRIQUE ESCAMOTABLE. REMARQUE : Prière de lire les informations importantes sur la sécurité figurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 36 www.sauder.com/service 429514...
Page 37
(JUEGO DE EXTENSIÓN SE MUESTRA POR SEPARADO) su referencia futura. Si RIEL DE EXTENSIÓN ..........4 necesita ponerse en EXTREMO DERECHO ..........1 contacto con Sauder en CORREDERA DE EXTENSIÓN ......4 PANEL SUPERIOR ............1 cuanto a esta unidad, CORRIMIENTO LARGO DE ARCHIVERO ...2 FONDO .................1...
Page 38
PASO 3 correspondientes indicados del EXTREMO DERECHO (B). Empuje trece EXCÉNTRICOS ESCONDIDOS GRANDES (7) en los DORSOS (F y G). Atornille siete BIELAS DE EXCÉNTRICO (9) en los agujeros correspondientes indicados de los DORSOS (F y G). Page 38 www.sauder.com/service 429514...
Page 39
PANEL SUPERIOR se inserten en los EXTREMOS y los DORSOS. Fije un POMO (12) a la CARA DE CAJÓN SUPERIOR (H). Utilice un TORNILLO PARA METAL de 22 mm (22). Repita este paso para el otro cajón. 429514 www.sauder.com/service Page 39...
Page 40
EXCÉNTRICO ESCONDIDO. NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. Page 40 www.sauder.com/service 429514...
Page 41
Les téléviseurs peuvent être très un téléviseur. téléviseur. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. 429514 www.sauder.com/service Page 41...
Page 42
Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y hacerlos propensos a volcarse hacia adelante. Page 42 www.sauder.com/service 429514...
