Hardware Identification
å
Screws are shown actual size. You may receive extra hardware with your unit.
(EXTENSION SET SHOWN SEPARATED)
1
EXTENSION RAIL - 4
NOTCHED FILE
5
GLIDE - 2
9
CAM SCREW - 44
LARGE WOOD
13
DOWEL - 24
Page 4
2
EXTENSION SLIDE - 4
6
FILE BAR - 4
INTERLOCK
10
MECHANISM - 1
SMALL WOOD
14
DOWEL - 20
www.sauder.com/service
LONG FILE
3
GLIDE - 2
LARGE HIDDEN
7
CAM - 34
DRAWER
11
ACTUATOR - 2
15
APPLIQUE CARD - 2
SHORT FILE
4
GLIDE - 4
SMALL HIDDEN
8
CAM - 10
12
KNOB - 2
LOCK
17
BRACKET - 1
