6. Installing the fitting
34
35
36
37
38
8.
Insert the module support with the fastening plate and the drill protec-
tion plate into the outer side of the door.
39
IMPORTANT
Damage to the sleeve nuts due to improper insertion
If the sleeve nut tabs are not located in the recesses, they can be damaged
during further installation. In such cases, the sleeve nut can rotate uninten-
tionally, which makes installation/removal difficult.
Ensure that the sleeve nut tabs are located in the recesses.
17
9.
Screw the washers and the inner plate firmly onto the module support
(SW6 short screws, SW5 long screw in the centre).
41
10. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre
of the spindle. Use a punch and hammer to make an indent in the ad-
apter sleeve to prevent it from slipping.
42
43
11.
Measure the total length of the spindle.
44
12.
Locate the inside of the spindle (four-edge end up to the centre of the
first groove = 26 mm).
13.
Use the table to determine the position of the O-ring.
45
36 / 64
SmartHandle AX Advanced Security fitting
Door thickness
Size
(mm)
S
39 - <41
S
39 - <41
S
41 – <46
S
41 – <46
S
46 - <50
S
50 - 55
M
54 - <56
M
54 - <56
M
56 – <61
M
56 – <61
M
61 – <66
M
61 – <66
M
66 – <71
M
71 - 75
L
74 - <76
L
74 - <76
L
76 – <81
L
76 – <81
L
81 – <86
L
81 – <86
L
86 – <91
L
91 - 95
14. Slide the O-ring onto the calculated groove.
46
15.
Insert the spindle into the door with the ring-free side as far as it will go.
47
16. Insert the filling profile onto the inner fixing plate.
48
17.
For 7 mm spindle: Place the adapter sleeve in the inside handle in such a
way that the recess faces the grub screw.
49
18. Determine the required direction of rotation for your inside handle.
19. Insert the spring element appropriately.
50
51
20. Place the inside handle unit on the spindle.
52
21.
Use the 12 mm screws to fasten the inner handle unit onto the fixing
plate (PH2).
53
54
22. Place the cover on top of the fastening plate.
55
23. Fold down the cover.
56
24. Slide the cover upwards.
57
25. Press the inlay into place.
58
Spindle length
Ring position
(mm)
104
2
114
4
104
1
114
3
114
2
114
1
124
3
134
5
124
2
134
4
124
1
134
3
134
2
134
1
144
3
154
5
144
2
154
4
144
1
154
3
154
2
154
1
EN
