6. Installing the fitting
Size
S
S
S
S
S
S
M
M
M
M
M
M
M
M
L
L
L
L
L
L
L
L
46
14 / 64
Door thickness (mm)
39 - <41
39 - <41
41 – <46
41 – <46
46 - <50
50 - 55
54 - <56
54 - <56
56 – <61
56 – <61
61 – <66
61 – <66
66 – <71
71 - 75
74 - <76
74 - <76
76 – <81
76 – <81
81 – <86
81 – <86
86 – <91
91 - 95
SmartHandle AX Advanced Security fitting
Spindle length (mm)
104
114
104
114
114
114
124
134
124
134
124
134
134
134
144
154
144
154
144
154
154
154
Ring position
2
4
1
3
2
1
3
5
2
4
1
3
2
1
3
5
2
4
1
3
2
1
Abbildungen/Images
