SmartHandle AX Advanced Security fitting
 Adapter set, 7 mm spindle
Adapter sleeve, 8.5 mm spindle

Adapter sleeve, 10 mm spindle

4. Design
1
5. Prepare door (drilling template)
ü Pin or scriber at hand.
Drill at hand.
ü
Suitable drill available (Ø 13 mm).
ü
PH2 screwdriver at hand.
ü
1. Insert the spindle into the mortise lock.
2
2. Place the drilling template on the spindle.
3
3. Align the drill template vertically using the printed scale.
4. Mark the drill holes with mark 1.
4
5. Remove the drilling template and rotate it 180 degrees.
5
6
6. Place the drilling template on the spindle.
7
7. Align the drill template vertically using the printed scale.
8. Mark the drill hole with mark 2.
8
9. Remove the drilling template and spindle.
9
10
10. Remove the mortise lock.
11
11. Drill the required holes.
12
12. Fit the mortise lock.
13
6. Installing the fitting
Door pre-drilled.
ü
ü PH2 screwdriver at hand.
ü TX15 screwdriver at hand.
ü Have an SW6 hex slotted-head screwdriver ready.
ü Have an SW5 hex slotted-head screwdriver ready.
ü Caliper gauge at hand.
1. Insert the spindle protective tube and the sleeve nuts into the fixing
plate (short sleeve nut in the middle).
14
2. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the
module support.
15
3. Insert the module support into the fastening plate.
16
EN
IMPORTANT
Damage to the sleeve nuts due to improper insertion
If the sleeve nut tabs are not located in the recesses, they can be damaged
during further installation. In such cases, the sleeve nut can rotate uninten-
tionally, which makes installation/removal difficult.
Ensure that the sleeve nut tabs are located in the recesses.

17
4. Slide the module support upwards.
18
9 Module support snaps into place.
5. Fasten the module support to the fixing plate (PH2) with the 16 mm
screws.
19
20
6. Measure the door thickness.
21
Door thickness
Size
(mm)
S 39 – <43
S 43 - <45
S 45 - <47
S 47 – <52
S 52 - <55
M 54 - <58
M 58 - <63
M 63 - <65
M 65 - <67
M 67 – <72
M 72 - <75
L 74 - <78
L 78 - <83
L 83 - <85
L 85 - <87
L 87 – <92
L 92 - <95
7. Determine what screws are required for the door thickness measured.
22
23
24
25
26
27
28
29
30
31
32
33
4. Design
Screws (M8) Screw (M6)
25 50
25 55
35 55
35 60
35 65
45 65
45 70
45 75
55 75
55 80
55 85
65 85
65 90
65 95
75 95
75 100
75 105
35 / 64
